How to Create A Pivot In Oracle?

10 minutes read

To create a pivot in Oracle, you can use the PIVOT operator in your SQL query. The PIVOT operator converts rows into columns, providing a summarized view of data. Here is a general structure of a pivot query:

1
2
3
4
5
6
7
SELECT <column1>, <column2>, ..., <pivot_column1>, <pivot_column2>, ...
FROM <table>
PIVOT (
    <aggregation_function>(<value_column>)
    FOR <pivot_column>
    IN (<value1>, <value2>, ...)
)


Here's a breakdown of the components involved:

  • , , ...: These are the columns you want to include in the final result set. They can be any valid column names within the table.
  • , , ...: These are the columns you want to pivot. They will become the new column headers in the output.
  • : This is the name of the table or view from which you want to retrieve data.
  • (): This is an aggregation function that you want to apply to the values when pivoting. Common examples include SUM, COUNT, AVG, etc.
  • : This is the column whose values you want to aggregate and display in the pivoted columns.
  • : This is the column that determines the unique values to be pivoted.
  • , , ...: These are the specific values from the that you want to pivot.


Make sure to replace <column1>, <column2>, ..., <pivot_column1>, <pivot_column2>, ..., <table>, <aggregation_function>, <value_column>, <pivot_column>, <value1>, <value2>, ... with appropriate values based on your specific scenario.


By utilizing the PIVOT operator and configuring the query correctly, you can easily create a pivot and transform your data in Oracle.

Best Oracle Books to Read in 2024

1
Oracle PL/SQL by Example (The Oracle Press Database and Data Science)

Rating is 5 out of 5

Oracle PL/SQL by Example (The Oracle Press Database and Data Science)

2
Oracle Database 12c DBA Handbook (Oracle Press)

Rating is 4.9 out of 5

Oracle Database 12c DBA Handbook (Oracle Press)

3
Oracle Database Administration: The Essential Refe: A Quick Reference for the Oracle DBA

Rating is 4.8 out of 5

Oracle Database Administration: The Essential Refe: A Quick Reference for the Oracle DBA

4
Oracle DBA Mentor: Succeeding as an Oracle Database Administrator

Rating is 4.7 out of 5

Oracle DBA Mentor: Succeeding as an Oracle Database Administrator

5
OCA Oracle Database SQL Exam Guide (Exam 1Z0-071) (Oracle Press)

Rating is 4.6 out of 5

OCA Oracle Database SQL Exam Guide (Exam 1Z0-071) (Oracle Press)

6
Oracle Database 12c SQL

Rating is 4.5 out of 5

Oracle Database 12c SQL

7
Oracle Autonomous Database in Enterprise Architecture: Utilize Oracle Cloud Infrastructure Autonomous Databases for better consolidation, automation, and security

Rating is 4.4 out of 5

Oracle Autonomous Database in Enterprise Architecture: Utilize Oracle Cloud Infrastructure Autonomous Databases for better consolidation, automation, and security


How to unpivot a pivot table in Oracle?

To unpivot a pivot table in Oracle, you can use the "UNPIVOT" clause or a combination of "UNION ALL" and "SELECT" statements. Here are the steps to unpivot a pivot table in Oracle:

  1. Identify the pivot table that you want to unpivot. This table should have multiple columns representing different categories or attributes.
  2. Determine the new structure of the unpivoted table. Decide on the desired column names that will represent the previously pivoted values.
  3. Use the "UNPIVOT" clause to unpivot the table. The "UNPIVOT" clause requires specifying the source table, the columns to keep as identifiers, and the columns to unpivot. Example: SELECT * FROM (SELECT identifier_column1, identifier_column2, pivoted_column1, pivoted_column2 FROM pivot_table) UNPIVOT (unpivoted_value FOR unpivoted_column IN (pivoted_column1, pivoted_column2)); In this example, pivot_table is the name of the pivot table you want to unpivot. identifier_column1 and identifier_column2 are the columns that you want to keep as identifiers, while pivoted_column1 and pivoted_column2 are the columns that you want to unpivot. unpivoted_column represents the new column that will contain the original column names, and unpivoted_value represents the values from the pivoted columns.
  4. Alternatively, you can use "UNION ALL" and multiple "SELECT" statements to achieve the same result. Each "SELECT" statement should retrieve a different column, and each retrieval should have the same set of identifier columns. Example: SELECT identifier_column1, identifier_column2, 'pivoted_column1' AS unpivoted_column, pivoted_column1 AS unpivoted_value FROM pivot_table UNION ALL SELECT identifier_column1, identifier_column2, 'pivoted_column2' AS unpivoted_column, pivoted_column2 AS unpivoted_value FROM pivot_table; In this example, pivot_table is the name of the pivot table you want to unpivot. You need to repeat the "SELECT" statement for each pivoted column, renaming it with a literal value in the 'pivoted_columnX' format.


By using either the "UNPIVOT" clause or a combination of "UNION ALL" and "SELECT" statements, you can successfully unpivot a pivot table in Oracle.


What is the performance impact of using pivot tables in Oracle?

Using pivot tables in Oracle can have a performance impact, as it involves aggregating and transforming data on the fly. The performance impact depends on various factors such as the complexity of the pivot operation, the size of the data being processed, and the hardware resources available.

  1. Data Volume: Pivot operations usually involve aggregating large amounts of data, which can impact performance. If the data volume is substantial, the pivot operation may require more time and resources to process.
  2. Aggregation Complexity: The complexity of the aggregation performed in the pivot table can affect performance. More complex aggregations, such as multiple levels of grouping or multiple aggregate functions, can increase the processing time.
  3. Indexing: Proper indexing of the underlying tables can significantly improve the performance of pivot table queries. Lack of appropriate indexes may result in slower query execution, especially when dealing with large datasets.
  4. Hardware Resources: The performance impact also depends on the hardware resources available. Sufficient CPU power, memory, and I/O capabilities are required to process pivot operations efficiently.
  5. Query Optimization: Like any other SQL query, optimizing the pivot table query by using appropriate join conditions, filtering clauses, and parallel execution techniques can enhance performance.


It is recommended to test and benchmark the specific pivot table operation with representative data to evaluate its performance impact in a particular Oracle environment.


How to create a dynamic pivot in Oracle?

To create a dynamic pivot in Oracle, you can use the following steps:

  1. Create a function that will generate the dynamic SQL query. This function should accept parameters for the columns and values that you want to pivot.
 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
CREATE OR REPLACE FUNCTION generate_pivot_query(pivot_column VARCHAR2, value_column VARCHAR2)
  RETURN VARCHAR2
IS
  pivot_query VARCHAR2(1000);
BEGIN
  pivot_query := 'SELECT * FROM (SELECT * FROM YOUR_TABLE)
                  PIVOT (SUM(' || value_column || ') FOR ' || pivot_column || ' IN (' || dynamic_columns || '))';

  RETURN pivot_query;
END;
/


  1. Create a procedure that will execute the dynamic SQL query generated by the function.
1
2
3
4
5
6
7
8
9
CREATE OR REPLACE PROCEDURE pivot_data(pivot_column VARCHAR2, value_column VARCHAR2)
IS
  dynamic_query VARCHAR2(1000);
BEGIN
  dynamic_query := generate_pivot_query(pivot_column, value_column);

  EXECUTE IMMEDIATE dynamic_query;
END;
/


  1. Call the procedure with the appropriate parameters to execute the dynamic pivot.
1
2
3
4
BEGIN
  pivot_data('pivot_column_name', 'value_column_name');
END;
/


Make sure to replace YOUR_TABLE with the name of your actual table, and pivot_column_name and value_column_name with the names of the columns you want to pivot. You can also modify the generated pivot query in the function to suit your specific requirements.


How to create a pivot in Oracle?

To create a pivot in Oracle, you can use the PIVOT operator. Here is an example of how to create a pivot:

  1. First, determine the columns you want to pivot and the values you want to display as columns in the pivoted result. For example, let's say you have a table called "sales" with the following columns: region, quarter, and amount.
  2. Write a query that includes the PIVOT operator. Here's an example:
 1
 2
 3
 4
 5
 6
 7
 8
 9
10
SELECT *
FROM (
  SELECT region, quarter, amount
  FROM sales
)
PIVOT (
  SUM(amount)
  FOR quarter IN ('Q1', 'Q2', 'Q3', 'Q4')
)
ORDER BY region;


In this example, we are summing the sales amount for each quarter. The PIVOT operator allows us to pivot the quarters ('Q1', 'Q2', 'Q3', 'Q4') as columns in the result.

  1. Replace the "sales" table and columns with your own table and columns.
  2. If you want to filter or aggregate the data further, you can add a WHERE clause or additional functions in the inner query.
  3. Execute the query to create the pivot result.


Note that the PIVOT operator is available in Oracle 11g and later versions.
