How to Export A Chart.js Chart to Excel?

16 minutes read

To export a chart.js chart to Excel, you can follow these steps:

  1. Prepare your chart: Create a chart using the chart.js library in your web application. Make sure the chart is fully rendered and visible on the webpage.
  2. Include the necessary libraries: To perform the export functionality, you need to include two additional libraries – FileSaver.js and TableExport.js. They help in saving the chart as an Excel file.
  3. Download the required libraries: Download the latest versions of FileSaver.js and TableExport.js or include them via CDN in your HTML file.
  4. Add the export button: Create a button on your webpage to trigger the export process. You can either create a simple HTML button or use an icon library like Font Awesome.
  5. Configure the export functionality: Within your JavaScript code, you need to configure the export functionality. Write code to handle the click event of the export button.
  6. Convert the chart to an image: Use the toBase64Image() function provided by chart.js to convert the chart to a base64 encoded image. This image will be embedded in the downloaded Excel file.
  7. Export the chart as Excel: Using the TableExport.js library, create an instance of TableExport and configure it to export your chart data. Set the export options to export in Excel format.
  8. Trigger the export: Within the click event handler for the export button, call the export() function of TableExport to trigger the export process.
  9. Test the export functionality: Save your changes and test the webpage. Click the export button to generate and download the Excel file containing your chart.


By following these steps, you can successfully export a chart.js chart to Excel format and enable users to download and use the chart data in their preferred spreadsheet application like Microsoft Excel.

Best JavaScript Books to Read in 2024

1
JavaScript: The Definitive Guide: Master the World's Most-Used Programming Language

Rating is 5 out of 5

JavaScript: The Definitive Guide: Master the World's Most-Used Programming Language

2
Web Design with HTML, CSS, JavaScript and jQuery Set

Rating is 4.9 out of 5

Web Design with HTML, CSS, JavaScript and jQuery Set

3
JavaScript and jQuery: Interactive Front-End Web Development

Rating is 4.8 out of 5

JavaScript and jQuery: Interactive Front-End Web Development

  • JavaScript Jquery
  • Introduces core programming concepts in JavaScript and jQuery
  • Uses clear descriptions, inspiring examples, and easy-to-follow diagrams
4
JavaScript: The Comprehensive Guide to Learning Professional JavaScript Programming (The Rheinwerk Computing)

Rating is 4.7 out of 5

JavaScript: The Comprehensive Guide to Learning Professional JavaScript Programming (The Rheinwerk Computing)

5
JavaScript from Beginner to Professional: Learn JavaScript quickly by building fun, interactive, and dynamic web apps, games, and pages

Rating is 4.6 out of 5

JavaScript from Beginner to Professional: Learn JavaScript quickly by building fun, interactive, and dynamic web apps, games, and pages

6
JavaScript All-in-One For Dummies

Rating is 4.5 out of 5

JavaScript All-in-One For Dummies

7
Learn JavaScript Quickly: A Complete Beginner’s Guide to Learning JavaScript, Even If You’re New to Programming (Crash Course With Hands-On Project)

Rating is 4.4 out of 5

Learn JavaScript Quickly: A Complete Beginner’s Guide to Learning JavaScript, Even If You’re New to Programming (Crash Course With Hands-On Project)

8
Eloquent JavaScript, 3rd Edition: A Modern Introduction to Programming

Rating is 4.3 out of 5

Eloquent JavaScript, 3rd Edition: A Modern Introduction to Programming

  • It can be a gift option
  • Comes with secure packaging
  • It is made up of premium quality material.
9
Head First JavaScript Programming: A Brain-Friendly Guide

Rating is 4.2 out of 5

Head First JavaScript Programming: A Brain-Friendly Guide

10
Learning JavaScript: JavaScript Essentials for Modern Application Development

Rating is 4.1 out of 5

Learning JavaScript: JavaScript Essentials for Modern Application Development

11
Learning PHP, MySQL & JavaScript: A Step-by-Step Guide to Creating Dynamic Websites (Learning PHP, MYSQL, Javascript, CSS & HTML5)

Rating is 4 out of 5

Learning PHP, MySQL & JavaScript: A Step-by-Step Guide to Creating Dynamic Websites (Learning PHP, MYSQL, Javascript, CSS & HTML5)

12
Learning JavaScript Design Patterns: A JavaScript and React Developer's Guide

Rating is 3.9 out of 5

Learning JavaScript Design Patterns: A JavaScript and React Developer's Guide

13
Professional JavaScript for Web Developers

Rating is 3.8 out of 5

Professional JavaScript for Web Developers


What is the recommended approach to export a chart.js line and bar combo chart to Excel?

To export a Chart.js line and bar combo chart to Excel, you would need to follow these steps:

  1. Fetch the data used to generate the chart in the desired format (e.g., an array of objects)
  2. Use a library like xlsx or exceljs to create an Excel workbook and worksheet.
  3. Add the data to the worksheet.
  4. Customize the layout and formatting of the data in the worksheet (if needed).
  5. Save the workbook as an Excel file.


Here's an example using the xlsx library:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
const XLSX = require('xlsx');

// Assuming you have an array of objects containing the data used in the Chart.js chart
const data = [
  { label: 'Category 1', barValue: 10, lineValue: 20 },
  { label: 'Category 2', barValue: 15, lineValue: 25 },
  // ...
];

// Create a new workbook and worksheet
const workbook = XLSX.utils.book_new();
const worksheet = XLSX.utils.json_to_sheet(data);

// Add headers to the worksheet
const headers = ['Label', 'Bar Value', 'Line Value'];
const headerRange = XLSX.utils.decode_range(worksheet['!ref']);
headers.forEach((header, colIndex) => {
  const cell = XLSX.utils.encode_cell({ r: 0, c: colIndex });
  worksheet[cell].v = header;
});

// Set column widths
const columns = [
  { wch: 15 }, // Label column width
  { wch: 10 }, // Bar Value column width
  { wch: 10 }, // Line Value column width
];
worksheet['!cols'] = columns;

// Add the worksheet to the workbook
XLSX.utils.book_append_sheet(workbook, worksheet, 'Chart Data');

// Save the workbook as an Excel file
XLSX.writeFile(workbook, 'chart-data.xlsx');


This example assumes that you have installed the xlsx library using npm or yarn. You can install it by running npm install xlsx or yarn add xlsx in your project directory.


After running this code, you will have an Excel file named "chart-data.xlsx" containing the exported data from the Chart.js chart. You can then open this file using Microsoft Excel or any other compatible spreadsheet software.


How to include a chart.js polar area chart in an Excel file?

To include a polar area chart from Chart.js in an Excel file, you'll need to follow these steps:

  1. Install the necessary libraries: First, you need to install the Chart.js and chartjs-node-canvas libraries. Open your command prompt or terminal and navigate to your project directory. Then, execute the following commands: npm install chart.js npm install chartjs-node-canvas
  2. Create a JavaScript file: Create a new JavaScript file in your project directory, e.g., chart.js.
  3. Import the necessary libraries: In your chart.js file, import the Chart.js and chartjs-node-canvas libraries using the following code: const { CanvasRenderService } = require('chartjs-node-canvas'); const Chart = require('chart.js');
  4. Define the chart data: Specify the data for your polar area chart as an object. For example: const chartData = { labels: ['Label 1', 'Label 2', 'Label 3', 'Label 4'], datasets: [{ data: [10, 20, 30, 40], // Example data backgroundColor: ['#FF6384', '#36A2EB', '#FFCE56', '#34E89E'], // Example colors }], };
  5. Create the chart: Use the Chart.js library to create a polar area chart. Below is an example snippet: const width = 400; // Chart width const height = 400; // Chart height const canvasRenderService = new CanvasRenderService(width, height, (ChartCallback) => { const chart = new ChartCallback( { type: 'polarArea', data: chartData, options: {} }, { width, height } ); return chart; });
  6. Save the chart as an image: Render the chart as an image using the toBufferSync function and save it to a file: fs.writeFileSync('chart.png', await canvasRenderService.renderToBuffer());


Now, you can open your Excel file and insert the chart.png image into a cell or chart object.


What is the easiest way to export a chart.js area chart to Excel?

The easiest way to export a Chart.js area chart to Excel is by using a JavaScript library called SheetJS. SheetJS allows you to generate and download an Excel file from JavaScript code.


Here is an example of how you can export a Chart.js area chart to Excel using SheetJS:

  1. Include the SheetJS library in your HTML file. You can use the following CDN link to include it:
1
<script src="https://unpkg.com/xlsx/dist/xlsx.full.min.js"></script>


  1. Add a button or trigger on your page to initiate the export process, for example:
1
<button id="export-btn">Export to Excel</button>


  1. Write the JavaScript code to export the chart to Excel when the button is clicked:
 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
document.getElementById('export-btn').addEventListener('click', function () {
  var chartData = myChart.data; // Get the data from your Chart.js chart
  var workbook = XLSX.utils.book_new();
  var sheetData = [];

  // Convert the chart data to Excel format
  for (var i = 0; i < chartData.labels.length; i++) {
    var rowData = [];
    rowData.push(chartData.labels[i]);
    for (var j = 0; j < chartData.datasets.length; j++) {
      rowData.push(chartData.datasets[j].data[i]);
    }
    sheetData.push(rowData);
  }

  // Add the data to the worksheet
  var worksheet = XLSX.utils.aoa_to_sheet(sheetData);
  XLSX.utils.book_append_sheet(workbook, worksheet, 'Sheet1');

  // Export the workbook to an Excel file
  var excelFileName = 'chart_data.xlsx';
  XLSX.writeFile(workbook, excelFileName);
});


Make sure to replace myChart with the variable name of your Chart.js chart object.

  1. Test your page. When the "Export to Excel" button is clicked, the chart data will be converted to an Excel file (chart_data.xlsx) and downloaded to the user's device.


Note: This solution requires the browser to support HTML5 File API for downloading files.


How can I export a chart.js radar chart to an Excel file?

To export a Chart.js radar chart to an Excel file, you will need to use a data export library or module. Here's a general approach you can follow:

  1. Retrieve the data used to plot the radar chart from the Chart.js dataset.
  2. Format the data in a format compatible with Excel, such as CSV or JSON.
  3. Use a library or module to export the formatted data to an Excel file format like .xlsx.


Here's an example using the "xlsx" library in JavaScript:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
// Step 1: Retrieve data from Chart.js dataset
const chartData = radarChart.data.datasets[0].data;

// Step 2: Format data as an array of arrays (2D array)
const formattedData = chartData.map((value, index) => [
  radarChart.data.labels[index],
  value,
]);

// Step 3: Export the formatted data to an Excel file
const XLSX = require('xlsx');
const workbook = XLSX.utils.book_new();
const worksheet = XLSX.utils.aoa_to_sheet(formattedData);
XLSX.utils.book_append_sheet(workbook, worksheet, 'Radar Chart Data');
XLSX.writeFile(workbook, 'radar_chart_data.xlsx');


In the above example, replace radarChart with the actual reference to your Chart.js radar chart object. The exported file will be named "radar_chart_data.xlsx" in the same directory where you run the code.


Note: Ensure you have installed the "xlsx" library by running npm install xlsx before using this example.


What methods can I use to export a chart.js chart to Excel?

There are a few different methods you can use to export a Chart.js chart to Excel:

  1. CSV Export: Chart.js does not have a built-in export functionality, but you can export your chart data as a CSV (comma-separated values) file, which can be opened in Excel. You can use JavaScript libraries like papaparse or csv-parser to convert the chart data into a CSV file.
  2. Data URL Export: You can convert your Chart.js chart to a data URL using the toDataURL() method, and then create a downloadable Excel file with that data URL. You can use JavaScript libraries like xlsx or file-saver to generate and save the Excel file.
  3. Server-Side Export: Instead of exporting the chart directly from the client-side, you can send the chart data to the server and have the server generate and save the Excel file. You can use server-side programming languages like PHP, Node.js, or Python, along with libraries like xlsx-populate, xlsx, or openpyxl, to create the Excel file on the server.


These methods provide different levels of complexity and customization. You can choose the one that best suits your requirements and technical skills.
